What is a Y-Strainer?

A Y-strainer is a mechanical filter used in pipelines to remove debris such as rust, scale, or other solids from the flow of liquids. The Y-shape design allows fluid to pass through the main line while diverting unwanted particles into a filtering chamber. This helps protect pumps, valves, and other pipeline equipment from damage and clogging.

How It Works

The BV511 Cast Iron Y-Strainer uses a mesh screen positioned at an angle inside the body. As the fluid flows through the strainer, solid particles are captured by the 20-mesh stainless steel screen, while clean water continues through the pipeline. The screen can be easily accessed and cleaned via the threaded cap at the bottom.

Product Overview

The BV511 is a high-performance cast iron Y-strainer designed for general water filtration applications. It ensures full-flow filtering performance and long service life with minimal maintenance. This model follows standard face-to-face dimensions and meets global flange connection standards.

Key Features

• Standard structure length for easy pipeline integration
• 20 mesh full-flow filtration screen for effective debris removal
• Durable cast iron body for long-lasting performance
• Low maintenance with removable screen access

Applications

• Municipal water supply systems
• Commercial and residential plumbing
• Irrigation systems
• Industrial water pipelines
