Product series
Slowly closed check valve
1.Product model: W816/836
2.Connection method: Flange
3.Applicable medium: Water
Category:
- Product details
-
PRODUCT HIGHLIGHTS
Gentle action, no impact, easy to adjust and maintain, excellent and reliable sealing performance, controllable opening speed and closing speed, piping is equipped with filter device to prevent clogging.
PRODUCT PARAMETERS
Working pressure level Interface form and standard Temperature, medium PN10 / PN16 / PN25 / 150LB / 10K / 16K Flange connection, in accordance with: GB / ANSI / BSEN / ISO / DIN / JIS 0 ℃ ～ 80 ℃ normal temperature water Part name Material Valve body Ductile iron / stainless steel Valve cover Ductile iron / stainless steel Spring Stainless steel Diaphragm NBR / VITON Ball valve Brass / stainless steel Needle valve Brass / stainless steel Filter Brass / stainless steel Check valve Brass / stainless steel APPLICATIONS
